| Place of Origin: | CHINA |
|---|---|
| Brand Name: | YZGEAR |
| Model Number: | BG2207001 |
| Minimum Order Quantity: | 1 Set |
| Price: | $300.0/Set |
| Packaging Details: | Plywood Crate |
| Delivery Time: | 55 Days |
| Payment Terms: | L/C,D/P,T/T,Western Union |
| Supply Ability: | 200 Sets/Month |
| Material: | 42CrMo/AISI 4140 | Heat Treatment: | Induction Hardening |
|---|---|---|---|
| Hardness: | Gear 50-55 HRC Pinion 58-62 HRC | Gear Quality: | ISO 8-9 Grade |
| Module: | 11.5 | Tip Diameter: | 550mm |
| Highlight: | 42CrMo straight bevel gear system,Straight Tooth Bevel Gear System,Cone Crusher Straight Tooth Bevel Gear |
||
| Attribute | Value |
|---|---|
| Material | 42CrMo/AISI 4140 |
| Heat Treatment | Induction Hardening |
| Hardness | Gear 50-55 HRC, Pinion 58-62 HRC |
| Gear Quality | ISO 8-9 Grade |
| Module | 11.5 |
| Tip Diameter | 550mm |
Straight bevel gear is a gear with tapered conical teeth elements that have the same direction. This type is both the simplest to produce and the most widely used in the bevel gear category.
| Feature | Specification |
|---|---|
| Custom Made | Available |
| Shaft Angle | 90° |
| Gear Teeth Manufacturing | Gear Shaping |
| Module (M) | 12.5 |
| Number of Teeth (Z) | 26/60 |
| Pressure Angle (α) | 20° |
| Teeth Accuracy Grade | ISO 8-9 Grade |
| Heat Treatment | Carburizing/Induction Hardening |
| Surface Hardness | Pinion 58-62 HRC/Gear 50-55 HRC |
| CHINA/GB | ISO | ГΟСТ | ASTM | JIS | DIN |
|---|---|---|---|---|---|
| 45 | C45E4 | 45 | 1045 | S45C | CK45 |
| 40Cr | 41Cr4 | 40X | 5140 | SCr440 | 41Cr4 |
| 20CrMo | 18CrMo4 | 20ХМ | 4118 | SCM22 | 25CrMo4 |
| 42CrMo | 42CrMo4 | 38XM | 4140 | SCM440 | 42CrMo4 |
| 20CrMnTi | 18XГT | SMK22 | |||
| 20Cr2Ni4 | 20X2H4A | ||||
| 20CrNiMo | 20CrNiMo2 | 20XHM | 8720 | SNCM220 | 21NiCrMo2 |
| 40CrNiMoA | 40XH2MA/40XHMA | 4340 | SNCM439 | 40NiCrMo6/36NiCrMo4 | |
| 20CrNi2Mo | 20NiCrMo7 | 20XH2MA | 4320 | SNCM420 |
