| Place of Origin | CHINA |
| Brand Name | YIZGEAR |
| Certification | QC |
| Model Number | C50LR-BR16-4 |
Fastener Ring-Grooved lock bolt Blind Rivet Bolts 12 1/2" C50LR-BR16-4
Lock bolts offer several benefits over traditional fasteners like nuts and bolts.
They are easy and quick to install, reducing assembly time and labor costs.
They also eliminate the need for access to the backside of the joint, as they are installed from one side only.
This makes lock bolts ideal for applications where one side of the joint is inaccessible or where disassembly is not required.
| Nominal Diameter | Actual Diameter | Nominal Riveting Thickness | Actual Riveting Thickness | Huck Model | Avdel Model | ||
| Min | Max | Min | Max | ||||
| 12 (1/2”) |
12.5 | 13.1 | 6 | 6.35 | 12.7 | C50LR-BR16-4 | 02861-01604 |
| 12 | 12.7 | 19.1 | C50LR-BR16-8 | 02861-01608 | |||
| 18 | 19.1 | 25.4 | C50LR-BR16-12 | 02861-01612 | |||
| 24 | 25.4 | 31.8 | C50LR-BR16-16 | 02861-01616 | |||
| 31 | 31.8 | 38.1 | C50LR-BR16-20 | 02861-01620 | |||
| 37 | 38.1 | 44.5 | C50LR-BR16-24 | 02861-01624 | |||
| 44 | 44.5 | 50.8 | C50LR-BR16-28 | 02861-01628 | |||
| 50 | 50.8 | 57.2 | C50LR-BR16-32 | 02861-01632 | |||
| 57 | 57.2 | 63.5 | C50LR-BR16-36 | 02861-01636 | |||
| 63 | 63.5 | 69.9 | C50LR-BR16-40 | 02861-01640 | |||
| 70 | 69.8 | 76.2 | C50LR-BR16-44 | 02861-01644 | |||
| 77 | 76.2 | 82.6 | C50LR-BR16-48 | 02861-01648 | |||
| 83 | 82.6 | 88.9 | C50LR-BR16-52 | 02861-01652 | |||
| 89 | 88.9 | 95.3 | C50LR-BR16-56 | 02861-01656 | |||
| 95 | 95.3 | 101.6 | C50LR-BR16-60 | 02861-01660 |
