| Place of Origin: | CHINA |
|---|---|
| Brand Name: | YZGEAR |
| Model Number: | BG22123105 |
| Minimum Order Quantity: | 1 Set |
| Price: | $300.0/Set |
| Packaging Details: | Plywood Crate |
| Delivery Time: | 55 Days |
| Payment Terms: | L/C, D/P, T/T, Western Union |
| Supply Ability: | 800 Sets/Month |
| Module: | 0.5 | Teeth Number: | 44T |
|---|---|---|---|
| Material: | 45# | Heat Treatment: | Induction Hardened |
| Hardness: | 45-50 HRC | Quality Grade: | ISO 8-9 Grade |
| Highlight: | 0.5 Module Transmission Gear,43T Micro Transmission Gear,Straight Conical Transmission Gear |
||
0.5 Module 43T Micro Straight Conical Gear Transmission Gear
1) Aplicaciones de engranajes cónicos rectos
Máquinas herramientas, herramientas eléctricas. imprenta, caja de cambios.
2) Descripción de los engranajes cónicos
Engranajes cónicos utilizados para conectar dos ejes cuyos ejes se cortan y las superficies de paso son conos.
Los dientes del engranaje cónico se cortan a lo largo del cono de paso.
El engranaje cónico recto es una forma simple de engranaje cónico que tiene dientes rectos.
| Products | Straight Bevel Gear |
| Custom Made | √ |
| Shaft Angle | 90° |
| Gear Teeth manufacturing | Gear Shaping |
| Gear Teeth Grinding | |
| Module (M) | 7 |
| Number of Teeth (Z) | 18/18 |
| Pressure Angle (α) | 20° |
| Teeth Accuracy Grade | ISO 8-9 Grade |
| Heat Treatment | Carburizing/ Induction Hardending |
| Surface Hardness | Pinion 58-62 HRC Gear 50-55 HRC |
| STEEL CODE GRADES COMPARISON | |||||
| CHINA/GB | ISO | ГΟСТ | ASTM | JIS | DIN |
| 45 | C45E4 | 45 | 1045 | S45C | CK45 |
| 40Cr | 41Cr4 | 40X | 5140 | SCr440 | 41Cr4 |
| 20CrMo | 18CrMo4 | 20ХМ | 4118 | SCM22 | 25CrMo4 |
| 42CrMo | 42CrMo4 | 38XM | 4140 | SCM440 | 42CrMo4 |
| 20CrMnTi | 18XГT | SMK22 | |||
| 20Cr2Ni4 | 20X2H4A | ||||
| 20CrNiMo | 20CrNiMo2 | 20XHM | 8720 | SNCM220 | 21NiCrMo2 |
| 40CrNiMoA | 40XH2MA/ 40XHMA |
4340 | SNCM439 | 40NiCrMo6/ 36NiCrMo4 |
|
| 20CrNi2Mo | 20NiCrMo7 | 20XH2MA | 4320 | SNCM420 | |
