Number Of Teeth: | Custom | Hradness: | 220-260 HB |
---|---|---|---|
Profile: | Conical Gear | Manufacturing Process: | Gear Shaping |
Module: | 10 | Manufacturing Method: | Gear Hobbing |
Highlight: | Long Service Life Transmission Gears,High Reliability Transmission Gears,Automated Inspection Equipment Transmission Gears |
1) Description of Rack Gear
In automated equipment, the rack is one of the core components for achieving automated linear motion.
It works in conjunction with the motor and gears, and is controlled by the system to achieve precise positioning and motion control.
2) Feature of Rack Gear
a) The positioning accuracy is high, which can meet the strict requirements of automated equipment for motion precision.
b) The response speed is fast, enabling rapid start, stop and direction change.
c) It can be integrated with various drive devices, such as servo motors and stepper motors, to achieve intelligent control.
3) Advantage of Rack Gear
a) Improve the working efficiency and production quality of automated equipment, and reduce the need for manual intervention.
b) The motion control is flexible and can adjust the motion parameters according to different production process requirements.
c) High reliability, reducing the occurrence rate of equipment failures and extending the equipment's service life.
4) Application of Rack Gear
It is widely applied in automated warehousing systems to achieve automatic storage and retrieval of goods;
in industrial robots, it is used for the linear movement of robot arms to complete various complex operation tasks;
it is also used in automated inspection equipment to achieve precise movement and positioning of inspection probes.
Products | Rack Gears |
Custom Made | √ |
Gear Profile Type | Rack Gears |
Gear Teeth manufacturing | Gear Milling |
Gear Teeth Grinding | If needed |
Module (M) | Custom |
Number of Teeth (Z) | Custom |
Pressure Angle (α) | |
Helix Angle (β) | Custom |
Teeth Accuracy Grade | ISO 8-9 Grade |
Heat Treatment | Induction Hardening |
Surface Hardness | 200-230HB/ 40-45 HRC |
STEEL CODE GRADES COMPARISON | |||||
CHINA/GB | ISO | ГΟСТ | ASTM | JIS | DIN |
45 | C45E4 | 45 | 1045 | S45C | CK45 |
40Cr | 41Cr4 | 40X | 5140 | SCr440 | 41Cr4 |
20CrMo | 18CrMo4 | 20ХМ | 4118 | SCM22 | 25CrMo4 |
42CrMo | 42CrMo4 | 38XM | 4140 | SCM440 | 42CrMo4 |
20CrMnTi | 18XГT | SMK22 | |||
20Cr2Ni4 | 20X2H4A | ||||
20CrNiMo | 20CrNiMo2 | 20XHM | 8720 | SNCM220 | 21NiCrMo2 |
40CrNiMoA | 40XH2MA/ 40XHMA |
4340 | SNCM439 | 40NiCrMo6/ 36NiCrMo4 |
|
20CrNi2Mo | 20NiCrMo7 | 20XH2MA | 4320 | SNCM420 |
