1.5 Module 56 Tooth Metal Spur Gear For Hand Wheel Gear Reducers

1.5 Module 56T Customized Spur Gears For Hand Wheel Gear Reducers

1) Description of Spur Gear

Spur gears or straight-cut gears are the simplest type of  gear. They consist of a cylinder or disk with teeth

projecting radially. Viewing the gear at 90 degrees from the shaft length (side on) the tooth faces are straight

and aligned parallel to the axis of rotation. Looking down the length of the shaft, a tooth's cross section is

usually not triangular. Instead of being straight (as in a triangle) the sides of the cross section have a curved

form (usually involute and less commonly cycloidal) to achieve a constant drive ratio. Spur gears mesh together

correctly only if fitted to parallel shafts.

2) Pressure angle of Spur Gear

Spur gear can be classified into two pressure agnles.

20° being the current industry standard and 14½° being the former equipments.
